Description
Multi-gigabit networking with flexible PoE power
The LYSORA LS2P-16MG4XS-HP combines sixteen 2.5G Ethernet ports, four 10G SFP+ uplinks and a shared 370 W PoE budget. It provides twelve PoE/PoE+ ports and four PoE/PoE+/PoE++ ports.
Consider it for commercial projects combining compatible wireless access points, IP cameras and intercoms. Match each device’s power requirements to the appropriate port and allow capacity for future additions.
Management features
- Cloud, app and web administration.
- 802.1Q VLANs, voice VLAN and QoS.
- LACP and STP/RSTP/MSTP.
- IPv4 and IPv6 static routing.
- PoE watchdog, DHCP snooping and port isolation.
Technical specifications
| Copper port speeds | 10/100/1000/2500 Mbps |
|---|---|
| Switching capacity | 160 Gbps |
| Power input | 100–240 V AC, 50/60 Hz |
| Mounting | Rack or desktop |
| Cooling | Two fixed fans |
| Dimensions | 440 × 267.5 × 43.6 mm |
| Operating temperature | 0°C to 50°C |
| Manufacturer-listed warranty | 3 years |
Size the installation using combined maximum device power requirements and the shared PoE budget.
Plan your network with Alpha Intercom
Source networking and security equipment through Alpha Intercom in Canada, with locations in Toronto and Laval serving the Montreal area. Explore our LYSORA routers and wireless access points to complete your project.
Contact Alpha Intercom for project pricing and product selection.
